Mobile Crushers
Mobile crushers are powerful, versatile machines designed to crush rocks and stones on-site. These portable units combine multiple functions—crushing, screening, and material transport—into a single process, streamlining operations and reducing the need for additional equipment.
In the construction industry, they significantly boost operational efficiency, lower costs, and contribute to sustainability by processing large volumes of material quickly. By breaking down rocks into smaller, usable sizes on-site, they help meet tight project deadlines while eliminating the need to transport materials to external facilities. This not only cuts transportation costs but also minimizes project delays.
Available in both track-mounted and wheeled models, mobile crushers offer flexibility and ease of transport, making them ideal for projects that require frequent relocation between job sites. Incorporating them into your operation enables you to optimize workflow, reduce environmental impact, and enhance overall productivity.
KLEEMANN’s Mobile Crushers
KLEEMANN’s mobile crushers are renowned for their cutting-edge design and efficiency in material processing, making them a trusted choice in the construction and mining industries. These machines are engineered to deliver superior performance across a wide range of applications, ensuring reliable and efficient crushing and screening on every job.
KLEEMANN offers a diverse lineup of mobile crushers, each tailored to meet specific project demands. Whether for heavy-duty mining or on-site construction, their equipment is built with a focus on maximizing efficiency while minimizing operational costs, helping businesses stay competitive and productive.
Mobile Jaw Crushers (MOBICAT)
The MOBICAT series is designed for the pre-crushing of nearly all types of natural stone and is also ideal for recycling applications. Renowned for their robust performance and versatility, the series offers key models that stand out for their ability to handle demanding tasks with efficiency and precision, including:
MC 100(i) EVO
The MC 100(i) EVO is the most compact mobile jaw crusher in the EVO line, offering a reliable solution for a range of construction tasks. Its versatility and efficiency make it ideal for demolition projects and contract crushing operations.
Key features include the low-consumption D-DRIVE diesel-direct drive, hydraulic crushing gap adjustment via the control system, an optional crusher unblocking system, and a feeding unit with integrated primary screening. This ensures smooth, efficient operation even in demanding environments.
Specification
- Feed capacity: up to around 220 t/h
- Crusher inlet size: 950 x 550 mm
- Weight: 31,000 kg
- Engine power:155 – 165 kW
MC 110(i) EVO2
This MC 110(i) EVO2 is a robust and versatile machine, engineered for pre-crushing natural stone and recycling materials. Its compact design, coupled with the intuitive SPECTIVE control system, makes it highly adaptable for a wide range of applications, ensuring both ease of use and reliable performance.
It stands out with its low-consumption D-DRIVE diesel-direct drive, independent double-deck prescreen, and advanced overload and control systems. It also offers an optional crusher unblocking system, all powered by the intuitive SPECTIVE operating concept, ensuring ease of use and optimized performance for a variety of applications.
Specification
- Feed capacity: up to about 400 t/h
- Crusher inlet size 1,100 x 700 mm
- Weight: 42,500 kg
- Engine power: 240 – 248 kW
MC 120(i) PRO
The MC 120(i) PRO is the flagship jaw crusher of the PRO line, engineered for exceptional durability and ease of maintenance. Built to withstand tough conditions, it delivers reliable performance even in demanding environments.
Key features include the energy-efficient E-DRIVE diesel-electric drive, the option for external power supply, an independent double-deck prescreen, an optional discharge chute, a crusher unblocking system, and the intuitive SPECTIVE operating concept for seamless control.
Specification
- Feed capacity: up to about 650 t/h
- Crusher inlet size: 1,200 x 800 mm
- Weight: 72,500 kg
- Engine power: 368 - 410 kW
Mobile Cone Crushers (MOBICONE)
KLEEMANN’s MOBICONE series offers mobile cone crushers specifically designed for the efficient processing of medium-hard to hard, abrasive natural stone. These crushers excel in delivering high-quality, cubic final grain sizes during secondary and tertiary crushing stages. Available in various sizes, MOBICONE plants provide versatility for a wide range of applications and integrate seamlessly with primary crushers and screening plants for optimized operations.
MCO 90(i) EVO2
The MCO 90(i) EVO2 is a mobile cone crusher specifically engineered for hard stone applications. Its compact size and advanced features ensure optimal performance across various projects, even in challenging conditions.
Equipped with a low-consumption D-DRIVE for enhanced efficiency, the crusher also features a Continuous Feed System for uninterrupted loading and overload protection systems for reliable operation. The SPECTIVE intuitive operating concept facilitates user-friendly control, while hydraulic crushing gap adjustment allows for precise settings. Additionally, an optional single- or double-deck post-screening unit enhances productivity further.
Specification
- Feed capacity: up to 270 t/h
- Crusher system size: 970 mm
- Weight: 33,500 kg
- Maximum feed size: 200 mm
MCO 110(i) PRO
The MOBICONE MCO 110(i) PRO is renowned for its robust design and dependable performance, engineered to thrive in challenging conditions while delivering consistent results with minimal maintenance.
This mobile cone crusher features an efficient E-DRIVE and offers an external power supply option. Its Continuous Feed System ensures uninterrupted loading, while innovative overload protection safeguards the equipment's integrity. Additionally, the intuitive SPECTIVE operating concept enhances usability, and hydraulic crushing gap adjustment is conveniently managed through the control system, allowing for precise operations.
Specification
- Feed capacity: up to 470 t/h
- Crusher system size: 1,120 mm
- Weight: 49,500 kg
- Maximum feed size: 240 mm
Mobile Impact Crushers (MOBIREX)
KLEEMANN’s mobile impact crushers are engineered for exceptional productivity and versatility, adeptly processing soft to medium-hard natural stones. Each model is equipped with features specifically tailored to meet diverse operational requirements.
MR 110(i) EVO2
The MR 110(i) EVO2 is expertly engineered for the efficient processing of asphalt, natural stone, and demolition waste. As a key member of the MOBIREX EVO2 series, it stands out for its exceptional efficiency and high-quality output, making it a reliable choice for various applications.
This equipment features a low-consumption D-DRIVE diesel-direct drive, hydraulic crushing gap adjustment via the control system, and an independent double-deck prescreen. For user-friendly operation, it includes the SPECTIVE intuitive operating concept and a Lock & Turn safety system. Additionally, an optional single- or double-deck post-screening unit enhances its versatility.
Specification
- Feed capacity: up to 350 t/h
- Crusher inlet size: 1,100 x 800 mm
- Weight: 44,500 kg
- Engine power: 368 – 371 kW
MR 130(i) EVO2
The MOBIREX MR 130(i) EVO2 mobile impact crusher is a versatile and cost-effective machine that produces high-quality final products. It achieves production rates similar to larger plants while its compact design ensures easy transport and quick setup.
Equipped with a low-consumption D-DRIVE diesel-direct drive and hydraulic gap adjustment, it features an independent double-deck prescreen, the SPECTIVE intuitive operating concept, and a Lock & Turn safety system. An optional single-deck post-screening unit is also available to enhance productivity.
Specification
- Feed capacity: up to 450 t/h
- Crusher inlet size: 1,300 x 900 mm
- Weight: 49,500 kg
- Engine power: 368 – 410 kW
MR 130i PRO
The MR 130i PRO is expertly designed for diverse applications in natural stone processing and recycling, effectively handling soft to medium-hard rocks. It prioritizes producing high-quality final products that meet stringent standards for concrete and asphalt aggregates, focusing on optimal grain shape, precise size distribution, and cleanliness.
Equipped with an E-DRIVE diesel-electric drive for enhanced efficiency, it also offers an option for an external power supply. Its independently vibrating prescreen improves material separation, while the intuitive SPECTIVE operating system ensures user-friendly control. Safety features include the Lock & Turn system, and an optional large double-deck post-screening unit further boosts productivity.
Specification
- Feed capacity: up to 600 t/h
- Crusher inlet size: 1,300 x 900 mm
- Weight: 64,000 kg
- Engine power: 580 kW
Multico: Reliable Supplier of KLEEMANN Mobile Crushers
KLEEMANN provides a comprehensive range of products renowned for their environmental efficiency, versatility, and exceptional output, establishing them as a top choice in the construction industry.
As the official supplier, Multico Prime Power Inc. ensures you receive outstanding quality and peak performance with every product. Committed to customer satisfaction, we possess a deep understanding of the industry, helping you find the right equipment tailored to your needs. Our knowledgeable team is always on hand to assist you with product selection, maintenance advice, and after-sales support. Discover more about Multico and KLEEMANN’s mobile crushers here.
